Mila Latch 4 Rollers Lift Lever Multipoint Door Lock
Price range: £ 44.99 through £ 54.59
Description
This part is discontinued and is no longer available.
However, for part AS470425: AS4704725 is a potential alternative. This replacement is the closest alternative but its not a perfect match. Some adjustment to the keeps will be required.
For part AS470445: ECO4R45 is a potential alternative. This lock will need the roller keeps to be repositioned. This is a single spindle version not a double spindle so if offset handles have been used, they will need to be replaced with inline handles.
For part AS47045: 503519AA is a potential alternative. Keeps will have to be repositioned and a new deadbolt keep supplied. Part: AS47047 is also potential alternative. This replacement is the closest alternative but its not a perfect match. Some adjustment to the keeps will be required.
For part AS47040: AS4704728 is a potential alternative. Closest alternative adjustments will need to be made. Part: 50280019AA is also a potential alternative. This is a similar size lock but the roller keeps will need to be repositioned.
Additional information
| Discontinued | Yes |
|---|---|
| Backset | 25mm, 28mm, 45mm, 35mm |
| Centres PZ | 92mm |
| Faceplate | Flat 16mm – Square Ends |
| Spindle Size | 8mm |
| Rollers | 4 |
| Latch | 1 |
| Main Gearbox | Latch only |
| Operation | Lift Lever |
| Shootbolt Attachments | No |
| Spindle | Single 8mm |
| 1, 2 or 3 Piece | 1 |
| Handing | Non Handed |
| Distance Between Inner Locking Points | 596mm |
| Distance Between Outer Locking Points | 1638mm |
| Height | 2200mm |
| Top Roller To Spindle | 819mm |
| Bottom Roller To Spindle | 819mm |
